Product Summary

The NTB60N06G is a Power MOSFET. It is designed for low voltage, high speed switching applications in power supplies, converters and power motor controls and bridge circuits.

Parametrics

NTB60N06G absolute maximum ratings: (1)Drain-to-Source Voltage:60 Vdc; (2)Drain-to-Gate Voltage (RGS = 10 MΩ):60 Vdc; (3)Gate-to-Source Voltage: Continuous:±20Vdc,Non-Repetitive (tp≤10 ms):±30Vdc; (4)Drain Current: Continuous @ TA = 25℃:60Adc,Continuous @ TA = 100℃:42.3Adc, Single Pulse (tp≤10μs):180Apk; (5)Operating and Storage Temperature Range:-55℃ to +175℃.

Features

NTB60N06G feature: Pb-Free Packages are Available.

Diagrams

NTB60N06G internal diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
NTB60N06G
NTB60N06G
ON Semiconductor
MOSFET 60V 60A N-Channel
Data Sheet
Negotiable
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
NTB60N06
NTB60N06
ON Semiconductor
MOSFET 60V 60A N-Channel
Data Sheet
Negotiable
NTB60N06G
NTB60N06G
ON Semiconductor
MOSFET 60V 60A N-Channel
Data Sheet
Negotiable
NTB60N06T4
NTB60N06T4
ON Semiconductor
MOSFET 60V 60A N-Channel
Data Sheet
Negotiable
NTB60N06T4G
NTB60N06T4G
ON Semiconductor
MOSFET 60V 60A N-Channel
Data Sheet
0-1: $1.38
1-25: $1.17
25-100: $0.86
100-500: $0.73
500-800: $0.73
NTB6410ANG
NTB6410ANG
ON Semiconductor
MOSFET NFET D2PAK 100V 76A 13MOH
Data Sheet
0-1: $1.71
1-25: $1.49
25-100: $1.28
100-250: $1.12
NTB6410ANT4G
NTB6410ANT4G
ON Semiconductor
MOSFET NFET D2PAK 100V 76A 13MOH
Data Sheet
0-440: $1.18
440-500: $1.06
500-800: $1.06
800-1000: $0.89
