Product Summary

The is BCV47 an NPN Darlington transistor in a SOT23 plastic package. PNP complements: BCV26 and BCV46. The is uesed for preamplifier input applications.

Parametrics

BCV47 absolute maximum ratings: (1)VEBO emitter-base voltage open collector: 10 V; (2)IC collector current (DC): 500 mA; (3)ICM peak collector current: 800 mA; (4)IB base current: 100 mA; (5)Ptot total power dissipation Tamb 25 °C: 250 mW; (6)Tstg storage temperature: -65 +150 °C; (7)Tj junction temperature: - 150 °C; (8)Tamb operating ambient temperature: -65 +150 °C.

Features

BCV47 features: (1)Medium current (max. 500 mA); (2)Low voltage (max. 60 V); (3)High DC current gain (min. 20000).

Diagrams

BCV47 pin connection
