Product Summary
The TPS3600D33PW is a battery-backup supervisor for low-power processory. In case of power-fail or brownout conditions, the backup-battery switchover function of TPS3600D33PW allows to run a low-power processor and its peripherals from the installed backup battery without asserting a reset beforehand. The applications of the TPS3600D33PW include: (1)Fax Machines; (2)Set-Top Boxes; (3)Advanced Voice Mail Systems; (4)Portable Battery Powered Equipment; (5)Computer Equipment; (6)Advanced Modems; (7)Automotive Systems; (8)Portable Long-Time Monitoring Equipment; (9)Point of Sale Equipment.
Parametrics
TPS3600D33PW absolute maximum ratings: (1)Supply voltage: VDD: 7 V; MR and WDI: -0.3 V to (VDD + 0.3V); All other pins: -0.3 V to 7 V; (2)Continuous output current at VOUT: IO: 300 mA; All other pins, IO: ±10 mA; (3)Operating free-air temperature range, TA: -40℃ to 85℃; (4)Storage temperature range, Tstg: -65℃ to 150℃; (5)Lead temperature soldering 1,6 mm (1/16 inch) from case for 10 seconds: 260℃.
Features
TPS3600D33PW features: (1)Supply Current of 40 μA (Max); (2)Precision Supply Voltage Monitor: 2.0 V, 2.5 V, 3.3 V, 5.0 V; Other Versions on Request; (3)Watchdog Timer With 800-ms Time-Out; (4)Backup-Battery Voltage Can Exceed VDD; (5)Power-On Reset Generator With Fixed 100-ms Reset Delay Time; (6)Battery OK Output; (7)Voltage Monitor for Power-Fail or Low-Battery Monitoring; (8)Manual Switchover to Battery-Backup Mode; (9)Chip-Enable Gating -3 ns (at VDD = 5 V) Max. Propagation Delay; (10)Manual Reset; (11)Battery Freshness Seal; (12)14-Pin TSSOP Package; (13)Temperature Range: 40℃ to 85℃.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TPS3600D33PW |
Texas Instruments |
Supervisory Circuits Battery-Backup for LP Processor |
Data Sheet |
|
|
||||||||||||
|
TPS3600D33PWG4 |
Texas Instruments |
Supervisory Circuits Battery-Backup for LP Processor |
Data Sheet |
|
|
||||||||||||
|
TPS3600D33PWRG4 |
Texas Instruments |
Supervisory Circuits Battery-Backup for LP Processor |
Data Sheet |
|
|
||||||||||||
|
TPS3600D33PWR |
Texas Instruments |
Supervisory Circuits Battery-Backup for LP Processor |
Data Sheet |
|
|
||||||||||||
