Product Summary

The MPSE1 is a metallized polypropylene film capacitor.

Parametrics

MPSE1 specifications: (1)Category temperature: -40℃ to +105℃; (2)Rated voltage (UR): 250VDC, 450VDC, 630VDC; (3)Capacitance tolerance: ±3%(H), ±5%(J), ±10%(K); (4)tanδ: 0.001max at 1kHz; (5)Voltage proof: UR×150% 60s; (6)Insulation resistance: 0.33μF≧:25000MΩmin; 0.33μF<: 7500ΩFmin; (7)Reference standard: JIS C 5101-16, JIS C 5101-1.

Features

MPSE1 features: (1)Low dissipation factor, small and high current; (2)For applications where high frequency, high current are required(TV, display monitor, power supply, lighting lnverter, etc); (3)Coated with flame-retardant (UL94 V-0) epoxy resin; (4)RoHS compliance.

Diagrams

MPSE1 dimensions
