Product Summary
The MAX418ESD is a low-voltage, micropower, precision op amp designed for battery-operated systems. The MAX418ESD features a supply current of less than 1.2uA per amplifier that is relatively constant over the entire supply range, which represents a 15 to 20 times improvement over industry-standard micropower op amps. The applications of the MAX418ESD are battery-powered systems, medical instruments, electrometer amplifiers, intrinsically safe systems, photodiode pre-amps, pH meters.
Parametrics
MAX418ESD absolute maximum ratings: (1)total supply voltage:12V; (2)input voltage:(V+ + 0.3V) to (V- - 0.3V); (3)continuous current: 10mA or 50mA; (4)short-circuit duration:continuous; (5)continuous power dissipation:667mW; (6)operating temperature range:-40 to 85℃; (7)storage temperature range:-65 to 160℃; (8)lead temperature:300℃.
Features
MAX418ESD features: (1)1.2uA max quiescent current per amplifier; (2)+2.5V to +10V single-supply range; (3)500uV max offset voltage; (4)＜0.1pA typical input bias current; (5)output swings rail-to-rail; (6)input voltage range includes negative rail.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX418ESD |
Maxim Integrated Products |
Operational Amplifiers - Op Amps Quad 1.2uA Max Single-Supply |
Data Sheet |
Negotiable |
|
||||
 |
MAX418ESD+T |
Maxim Integrated Products |
Operational Amplifiers - Op Amps Quad 1.2uA Max Single-Supply |
Data Sheet |
Negotiable |
|
||||
|
MAX418ESD-T |
Maxim Integrated Products |
Operational Amplifiers - Op Amps Quad 1.2uA Max Single-Supply |
Data Sheet |
Negotiable |
|
||||
|
MAX418ESD+ |
Maxim Integrated Products |
Operational Amplifiers - Op Amps Quad 1.2uA Max Single-Supply |
Data Sheet |
Negotiable |
|
||||
